Glass Curtain Wall Installation And Solutions
Installation steps
1. Construction preparation:
Collect and prepare relevant materials and tools, such as insulating glass, connectors, sealants, measuring tools, etc.
Be familiar with the drawings, and provide technical training and briefing to technical workers.
Ensure that the construction site is clean and flat to meet the construction requirements.
Measurement and layout:
Use measuring tools such as theodolite and level to measure the center position of the connection point between the frame material and the main structure layer by layer on the main structure.
According to the design drawings, determine the installation position and size of the insulating glass.
3. Installation of connectors:
Fix the connectors according to the center position of the measured connection point to ensure that they are firm.
The connectors should meet the design requirements and have sufficient strength and stability.
4. Frame installation:
Install the main keel (strip) and level it, and then install the secondary keel (strip).
The frame material should meet the design requirements and be tightly connected with the connector.
5. Insulating glass installation:
Place the insulating glass in the frame according to the requirements of the design drawings.
Use sealant or rubber strips and other materials to fix the insulating glass to the frame to ensure sealing.
During the installation process, care should be taken to protect the insulating glass to avoid scratches or damage.
5. Gap treatment:
Use V-shaped, W-shaped or other shaped rubber strips to seal the gaps of the unit curtain wall.
Ensure that the sealant is filled densely without omissions.
6. Cleaning inspection:
Clean the stains and dust on the surface of the insulating glass and frame.
Check the installation quality and sealing of the insulating glass to ensure that it meets the requirements.
FAQ
1. Glass breakage
Q: Uneven force during installation, unqualified glass quality, etc.
A: Choose glass of qualified quality to ensure uniform force during installation.
2. Image deformation problem:
Q: Insulated glass is not flat enough, installation errors, etc.
A: Choose high-quality tempered glass to ensure the flatness of the glass surface; optimize glass thickness, spacing and other parameters; improve installation accuracy and reduce errors.
3. Insufficient sealing:
Q: poor sealant quality, aging or improper installation of sealing strips, etc.
A: Choose high-quality sealants and sealing strips; ensure that the sealant is filled densely without omissions; check the sealing regularly and replace the aged sealing strips in time.
4. Safety hazards:
Q: loose connectors, poor quality of frame materials, etc.
A: Regularly check the tightness of connectors and replace loose connectors in time; choose high-quality frame materials to ensure that they have sufficient strength and stability.
In summary, the installation of insulating glass for curtain wall buildings needs to follow certain steps and details, and there are corresponding solutions for possible problems. By strictly controlling the installation quality and detail processing, the safety and stability of the insulating glass curtain wall can be ensured.
Precautions:
During the construction process, strictly abide by the safety operating procedures and wear safety protection equipment. Ensure that the working platform and ladder are firm and stable to prevent high-altitude falling accidents. Pay attention to the operation during the handling and installation of glass to avoid damage and injury.
